Studer S20 OD Grinder

Currency:USD Category:Business & Industrial / Manufacturing & Metalworking Start Price:100.00 USD
Studer S20 OD Grinder
SOLD
1,825.00USD+ (273.75) buyer's premium + applicable fees & taxes.
This item SOLD at 2015 Jan 21 @ 13:47UTC-5 : EST/CDT
All items are sold AS-IS! Items are described to the best of our ability, but inspections are both invited and encouraged! There are no returns or refunds for items once removed from a premise!
LOCATION: Kalamazoo MI
LOADING FEE: $300


Studer S20 OD Grinder

Specifications:

Swing 160mm (6.29")

Center height 80mm (3.14")

Distance between centers 400mm (15.7")

Table Stroke 0-420mm (.039"-16.54")

Table Speed .4-11.5 ft/min

Table Swivel -30 deg

Workhead Speeds 60-1200 rpm

Wheel Head Swive 15 deg, 30 deg

Spindle Motor 2.2 kw. (3HP)

Rapid Advance & Retraction 1.18"

Infeed With Handwheel .98"

Max depth of plunge .075"

Coarse Adjustment 6.69"

Max Workpiece Weight 44 lbs

Table 700 x 105mm

Grinding Wheel Dimensions 300 x 30 x 127mm

Workhead Taper Morse #2

Footprint 57" x 43"
Control handle inches

Machine weight 2200 lbs

machine in plant not currently being used may require some repairs
