Extrude Hone Vector 8/6

Currency:USD Category:Business & Industrial / Metalworking - Equipment Start Price:100.00 USD
Extrude Hone Vector 8/6
SOLD
6,900.00USD+ (1,035.00) buyer's premium + applicable fees & taxes.
This item SOLD at 2020 Jul 30 @ 13:25UTC-4 : AST/EDT
Please reference the location of the lot in the "Item Description" tab. Lot locations may vary.

Appointments for inspections are available upon request, 8am-5pm M-F for each location. Please call 616-745-5953 or email sales@btmindustrial.com.



Location: White Bear Lake, MN (Customer Location)
*Note: Loading Fee $250
*Note: Just serviced with all new seals and other PM services

SPECIFICATIONS
208v
Media Cylinder Diameter 8 inches
Media Cylinder Capacity (Tube Displacement) 628.3 cu.in.
Hydraulic Cylinder Diameter 6 inches
Hydraulic Clamping Force 29.4 tons
Opening Between Tooling Plates (Max) 22 inches
Workable Height 47 inches
Distance Between Columns 21 inches
Compressed Air Required 56 PSI
Media Extrusion Pressure 200 - 900 PSI
Media Tube Displacement 62 inches
Approximate Overall Dimensions (Closed) 60”L x 60”W x 97”H
Approximate Weight 5000 pounds
Media Cylinder Diameter 8 inches
Media Cylinder Capacity (Tube Displacement) 628.3 cu.in.
Hydraulic Cylinder Diameter 6 inches
Hydraulic Clamping Force 29.4 tons
Opening Between Tooling Plates (Max) 22 inches
Workable Height 47 inches
Distance Between Columns 21 inches
Compressed Air Required 56 PSI
Media Extrusion Pressure 200 - 900 PSI
Media Tube Displacement 62 inches
Approximate Overall Dimensions (Closed) 60”L x 60”W x 97”H
Approximate Weight 5000 pounds
